Id 300 Mm Dwc Pipe Manufacturer Stockist Exporter
We are manufacturers, stockist and exporters of Id 300 Mm Dwc Pipe in Mumbai.
Synergy Engineering Solution is a recognized manufacturer, stockist, and exporter of robust and high-performance ID 300 mm DWC Pipes (Double Wall Corrugated Pipes). These pipes are specifically engineered using High-Density Polyethylene (HDPE) to meet the demanding requirements of modern underground infrastructure. The ID 300 mm variant, with its large internal diameter, is ideally suited for stormwater drainage, sewage networks, cable protection, and industrial discharge systems, where high flow capacity is essential.
The structure of the ID 300 mm DWC Pipe features a smooth inner surface for low frictional losses and a corrugated outer wall that offers superior strength and impact resistance. This dual-wall design ensures excellent performance under both static and dynamic loads. It also prevents deformation under pressure from soil or vehicular movement. These pipes are commonly used in large-scale utility projects such as urban sewer systems, roadway culverts, industrial zones, and power plant conduits.
Manufactured using advanced co-extrusion technology, Synergy’s DWC pipes conform to international standards like IS 16098 (Part 2), DIN 16961, and EN 13476. The ID 300 mm DWC Pipe is available in standard lengths of 6 meters, with SN4 and SN8 ring stiffness ratings, ensuring flexibility for various site conditions and load-bearing needs. The joints are secured using push-fit couplers and EPDM rubber rings, delivering leak-proof connections and simplified installation.
As a major stockist, Synergy Engineering Solution maintains large inventories of ID 300 mm DWC Pipes in both black and orange variants, allowing for quick dispatch to meet urgent infrastructure deadlines. These pipes are suitable for underground installations beneath roads, railway tracks, and airports, where reliable water or cable channeling is required. The smooth bore reduces sedimentation, and the pipe's non-corrosive nature ensures minimal maintenance.
Our Other Valuable Products
As a reputed exporter, Synergy supplies its ID 300 mm DWC Pipes to countries including Oman, Qatar, Saudi Arabia, UAE, Kuwait, Spain, Germany, the USA, Canada, and various nations across Africa and other global markets. With export packaging as per international standards, the company ensures product safety and quality during transportation. Each shipment includes material test certificates (MTCs), technical datasheets, and custom labeling as per client requirements.
The use of HDPE in manufacturing makes the ID 300 mm pipe resistant to chemicals, abrasion, and microbial attack. Moreover, the material is UV stabilized and recyclable, making these pipes a sustainable solution for long-term infrastructure planning. Their expected service life exceeds 50 years under standard underground conditions, delivering a solid return on investment.
Specification of Id 300 Mm Dwc Pipe
| Property | Description |
|---|---|
| Product Name | ID 300 mm DWC Pipe |
| Inner Diameter (ID) | 300 mm |
| Outer Diameter (Approx.) | 340 – 360 mm (varies with SN class) |
| Standard Length | 6 meters |
| Material | High-Density Polyethylene (HDPE) |
| Wall Type | Corrugated Outer Wall, Smooth Inner Wall |
| Ring Stiffness Classes | SN4, SN8 |
| Jointing System | Push-fit Coupler with EPDM Rubber Gasket |
| Standards | IS 16098 (Part 2), DIN 16961, EN 13476 |
| Applications | Sewerage, Drainage, Culverts, Cable Ducting, Utility Lines |
Chemical Composition of Id 300 Mm Dwc Pipe
| Component | Percentage (%) |
|---|---|
| Carbon (C) | ~85 – 87 |
| Hydrogen (H) | ~12 – 14 |
| Additives | <1 (UV stabilizers, antioxidants, colorants) |
Mechanical Properties of Id 300 Mm Dwc Pipe
| Property | Value |
|---|---|
| Density | 0.941 – 0.965 g/cm³ |
| Tensile Strength | ≥ 26 MPa |
| Flexural Modulus | 800 – 1200 MPa |
| Elongation at Break | ≥ 500% |
| Ring Stiffness (SN Ratings) | SN4, SN8 |
| Impact Resistance | Excellent |
| UV Resistance | High (Carbon Black Stabilized) |
| Operating Temperature Range | -40°C to +80°C |
| Expected Service Life | 50+ years |
Synergy also provides custom fabrication, site assistance, and technical consulting for large-scale government and private infrastructure projects. Their ability to offer complete drainage and ducting systems, coupled with dependable logistics and customer service, makes Synergy a leading name in the field of ID 300 mm DWC Pipe manufacturing and supply.
Pipe Testing Methods
Pipe Applications
