UNS N10276 Hastelloy C276 Weld Neck Wnrf Flanges Manufacturer Stockist Exporter
We are manufacturers, stockist and exporters of UNS N10276 Hastelloy C276 Weld Neck Wnrf Flanges in Mumbai.
UNS N10276 Hastelloy C276 Weld Neck WNRF Flanges are engineered to perform in the most extreme industrial environments, offering exceptional resistance to corrosion, pitting, and stress-corrosion cracking. Made from Hastelloy C276, a nickel-molybdenum-chromium alloy with added iron and tungsten, these flanges are well-suited for chemical processing, power generation, marine, and wastewater treatment industries. The Weld Neck Raised Face (WNRF) design ensures a robust and leak-free connection, ideal for systems operating under high pressure and temperature conditions.
Synergy Engineering Solution is a prominent manufacturer, stockist, and exporter of UNS N10276 Hastelloy C276 Weld Neck WNRF Flanges, offering high-quality products manufactured in compliance with international standards such as ASTM B564 and ASME B16.5. Their flanges are manufactured using advanced machinery, stringent quality control processes, and a commitment to precision engineering. With a reputation for reliability and performance, Synergy provides durable and high-performing flange solutions for demanding applications.
With a strong global presence, Synergy Engineering Solution exports these flanges to Oman, Qatar, Saudi Arabia, UAE, Kuwait, Spain, Germany, the USA, Canada, and multiple regions in Africa and worldwide. Their well-established logistics network, comprehensive inventory, and customer-first approach ensure fast delivery and responsive service for clients across industries. The company caters to both standard and custom specifications, offering flexibility for complex project requirements.
Hastelloy C276 is widely recognized for its ability to resist a wide range of aggressive chemicals, including strong oxidizers, ferric and cupric chlorides, hot contaminated mineral acids, and seawater. These properties make UNS N10276 flanges ideal for use in harsh environments like chemical reactors, pressure vessels, and pollution control systems. The alloy’s outstanding corrosion resistance ensures prolonged service life and reduced maintenance costs, even in the toughest applications.
Types Of Flanges manufacturer
Synergy Engineering Solution supplies these flanges in various pressure ratings (150#, 300#, 600#, etc.), dimensions, and face types (RF, RTJ) to suit diverse operational needs. All flanges undergo rigorous testing, including ultrasonic and radiographic inspections, and are delivered with mill test certificates and third-party inspection reports, ensuring full traceability and compliance with client specifications.
UNS N10276 Hastelloy C276 Weld Neck WNRF Flanges by Synergy Engineering Solution offer unmatched corrosion resistance, structural integrity, and global reliability. Trusted by major industries around the world, these flanges are the preferred choice for critical systems that demand the highest level of material performance and engineering precision.
Specifications of UNS N10276 Hastelloy C276 Weld Neck WNRF Flanges
| Specification | Details |
|---|---|
| Material | Hastelloy C276 / UNS N10276 |
| Flange Type | Weld Neck Raised Face (WNRF) |
| Standards | ASTM B564, ASME SB564, ANSI B16.5, B16.47, MSS SP-44 |
| Size Range | ½” to 48” (DN15 to DN1200) |
| Pressure Class | 150#, 300#, 600#, 900#, 1500#, 2500# |
| Face Type | Raised Face (RF), Ring Type Joint (RTJ), Flat Face (FF) |
| Connection Type | Welded (Butt-weld neck) |
| Operating Temperature | Up to 1040°C (1904°F) |
| Corrosion Resistance | Excellent resistance to strong oxidizers, acids, and seawater |
| Applications | Chemical processing, pollution control, marine, power generation |
| Certification | EN 10204 3.1 / 3.2, NACE MR0175, PED, IBR Approved |
| Manufacturer | Synergy Engineering Solution |
| Export Destinations | Oman, Qatar, Saudi Arabia, UAE, Kuwait, Spain, Germany, USA, Canada, Africa |
Chemical Properties of UNS N10276 Hastelloy C276 Weld Neck Wnrf Flanges
| Element | Composition (%) |
|---|---|
| Nickel (Ni) | Balance (approx. 57%) |
| Molybdenum (Mo) | 15.0 – 17.0 |
| Chromium (Cr) | 14.5 – 16.5 |
| Iron (Fe) | 4.0 – 7.0 |
| Tungsten (W) | 3.0 – 4.5 |
| Cobalt (Co) | ≤ 2.5 |
| Manganese (Mn) | ≤ 1.0 |
| Vanadium (V) | ≤ 0.35 |
| Silicon (Si) | ≤ 0.08 |
| Carbon (C) | ≤ 0.01 |
| Phosphorus (P) | ≤ 0.04 |
| Sulfur (S) | ≤ 0.03 |
Mechanical properties of UNS N10276 Hastelloy C276 Weld Neck Wnrf Flanges
| Property | Value |
|---|---|
| Tensile Strength (Minimum) | 760 MPa (110,000 psi) |
| Yield Strength (0.2% offset) | 283 MPa (41,000 psi) |
| Elongation (in 50 mm) | ≥ 40% |
| Hardness (Brinell) | ≤ 200 HB |
| Modulus of Elasticity | 205 GPa (29.7 x 10⁶ psi) |
| Melting Point | 1325 – 1370°C (2417 – 2498°F) |
| Density | 8.89 g/cm³ |
| Impact Strength | Excellent ductility and toughness |
| Operating Temperature Range | Cryogenic to 1040°C (1904°F) |
In order to alter the physical and mechanical characteristics of metal without altering its original shape and size, we offer a variety of heat treatment services, including hydrogen heat treatment, HIC testing, blasting and painting, cutting, arc welding, epoxy cutting, PMI testing, hydro testing, NACE testing, and SSC testing. Although heat treatment is frequently linked to a metal's increased strength, it can also be used to change specific manufacturability goals, such enhancing machinability, formability, ductility, etc. The metal and heavy manufacturing sectors use our services. Customers have expressed great pleasure with our services' precision, efficacy, cost, and prompt delivery.
Flanges Testing Methods
Flanges Applications
